PATTERN | STANDARD RIM | MAX LOAD (KG) | MAX PRESSURE (KPA) | TREAD DEPTH | SECTION WIDTH | OUTER DIAMETER | ||
| SINGLE | DUAL | SINGLE | DUAL | (mm) | (mm) | (mm) | ||
| HF313 | 6.50H | 1800 | 1600 | 740 | 740 | 16 | 235 | 855 |
| HF313 | 7 | 2575 | 2430 | 790 | 790 | 17 | 259 | 1019 |
| HF313 | 7.5 | 3250 | 3000 | 930 | 930 | 18 | 278 | 1054 |
| HF313 | 8 | 3550 | 3250 | 930 | 930 | 19 | 293 | 1085 |
| HF313 | 8.5 | 3790 | 3270 | 840 | 770 | 20 | 315 | 1125 |
| STM313 | 11.75 | 4500 | 4500 | 900 | - | 18.5 | 389 | 1072 |
