PATTERN | STANDARD RIM | MAX LOAD (KG) | MAX PRESSURE (KPA) | TREAD DEPTH | SECTION WIDTH | OUTER DIAMETER | ||
| SINGLE | DUAL | SINGLE | DUAL | (mm) | (mm) | (mm) | ||
| HF702 | 5.50F | 1150 | 1030 | 770 | 770 | 11 | 185 | 750 |
| HF702 | 5.50F | 1320 | 1180 | 770 | 770 | 14 | 200 | 775 |
| HF702 | 6.00G | 1500 | 1320 | 770 | 770 | 13 | 215 | 805 |
| HF702 | 6.50H | 1800 | 1600 | 770 | 770 | 15 | 235 | 855 |
| HF702 | 6.5 | 2430 | 2300 | 930 | 930 | 13.5 | 236 | 974 |
| HF702 | 7 | 2800 | 2650 | 900 | 900 | 15.5 | 259 | 1019 |
| HF702 | 7.5 | 3250 | 3000 | 930 | 930 | 16.5 | 278 | 1054 |
| HF702N | 7.5 | 3250 | 3000 | 930 | 930 | 16.5 | 278 | 1054 |
| HF702 | 8 | 3550 | 3250 | 930 | 930 | 17 | 293 | 1085 |
| HF702 | 8.5 | 3790 | 3270 | 840 | 770 | 17.5 | 315 | 1125 |
| HF702 | 8.5 | 4500 | 4125 | 900 | 900 | 16 | 315 | 1225 |
| HF702 | 8.25 | 3150 | 2900 | 850 | 850 | 15 | 279 | 1054 |
| HF702 | 9 | 3550 | 3250 | 930 | 930 | 16 | 300 | 1085 |
| HF702 | 9.75 | 4000 | 3550 | 860 | 860 | 16.5 | 320 | 1124 |
